Bus Node is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .


FESTO Order Number:8087559

SKU: CTEU-VN Category: Tag:


Dimensions W x L x H 40 mm x 91 mm x 50 mm
Pitch dimension [mm] 40
Fastening type auf Elektrik-Anschaltungauf Elektrik-Anschlussplatte
Product weight [g] 98
Fieldbus interface Ethernet
Fieldbus interface, report VARAN
Fieldbus interface, connection type 2x socket
Fieldbus interface, connection technology M12x1 D coded to EN 61076-2-101
Fieldbus interface, number of pins / wires 4
Fieldbus interface, galvanically separated yes
Fieldbus interface, transfer rate 100 Mbit/s
Internal cycle time 1 ms per 1 byte user data
Max. address volume inputs [Byte] 32
Max. address volume outputs [Byte] 32
Voltage supply, function Electronics and load
Voltage supply, connection type Plug
Voltage supply, connection technology M12x1 A coded to EN 61076-2-101
Voltage supply, number of poles/wires 5
Diagnosis UnterspannungKommunikationsfehlerSystemdiagnose
Parameterising Failsafe-ReaktionIO-Link Modus
Additional functions FFTVARAN Splitter
LED display product specific PS: Operating voltage electronics and load supplyX1: System status module I port 1X2: System status module I port 2
LED display bus specific XF1 AC: Netzwerk Datenverkehr Port 1XF1 LI: Netzwerk aktiv Port 1
Operating voltage range DC [V] 18 to 30
Nominal operating voltage DC [V] 24
Intrinsic power input at operating voltage Type 65 mA
Max. power supply [A] 4,0
Permission RCM mark
KC-mark KC-EMV
CE certificate (see declaration of conformity) to EU EMC directive
Corrosion resistant class KBK 2 – moderate corrosion stress
Bearing temperature [??C] -20 to 70
Protection category IP65IP67
Information about protection category in assembled conditionunused connection closed
ambient temperature [??C] -5 to 50
Housing material PA
Material information LABS containing materials includedRoHs compliant
Configuration support LASAL Baustein
