Description
Line designation Without sign holder
Electrical connection 1, function Field device screen
Electrical connection 1, design Angular
Electrical connection 1, connection type socket / container / ??.
Electrical connection 1, cable output Angled
Electrical connection 1, connection technology Wiring diagram F1
Electrical connection 1, number of pins / wires 31
Electrical connection 1, occupied pin / wire 31
Electrical connection 2, function Control screen
Electrical connection 2, connection type socket / container / ??.
Electrical connection 2, connection technology Wiring diagram F1
Electrical connection 2, number of pins / wires 31
Electrical connection 2, occupied pin / wire 31
Operating voltage range DC [V] 0 to 50
Nominal operating voltage DC [V] 24
Cable length [MTR] 0,50
Line properties f??r dynamische Anwendungen
Bending radius, moving cable placement [mm] >= 25 mm
Cable set up 31 Adern, Abstand 0,5 mm
Conductor – nominal cross-section [mm2] 0,0105
Protection category IP20
Information about protection category In mounted condition
ambient temperature [??C] -20 to 75
Ambient temperature for moving cable placements [??C] -5 to 70
CE certificate (see declaration of conformity) nach EU-RoHS-RL
Material information LABS containing materials includedRoHs compliant
Cable sleeve material PET
Cable shield colour Grey
Corrosion resistant class KBK 1 – low corrosion stress
Electrical connection 2, design Angular
Electrical connection 2, cable output Angled
Degree of contamination 1
Current carrying capacity at 40??C [A] 0,5
Surge voltage strength [kV] 0,25
Bending radius, permanent cable placement [mm] 0
Test conditions line Test conditions on request
Housing material PA
Housing colour black
Product weight [g] 27
Connection frequency 30
Elektrischer Anschluss 1, Hinweis zum Kabelabgang 90??
Electrical connection 1, fastening type Ratcheting lock
Bearing temperature [??C] -25 to 55
Plug contacts material Material of coupler tin plated
Electrical connection 2, fastening type Ratcheting lock
Elektrischer Anschluss 2, Hinweis zum Kabelabgang 90??
Hinweis zu Biegeradius, feste Kabelverlegung einmalig knickbar
