Pressure Gauge is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .


FESTO Order Number:8090378

SKU: PAGN-26-10-P10-RG Category: Tag:


Display range [bar] [bar] 0 to 10
Nominal size pressure gauge 26
Construction set up Pipe spring pressure gauge without measuring unit
Fastening type pipe installation
Operating medium Inert gasesNeutral liquids
Operating pressure [bar] 0 to 10
Factor alternating strain 0.66
Measurement precision class 4
Protection category IP43
Medium temperature [??C] -20 to 60
ambient temperature [??C] -20 to 60
Material information RoHs compliant
Connection position Back side centred
Pneumatic connection Cartridge 10 mm
From medium contacting materials Brass
Stud material Brass
Housing material PA
Window material PS
Housing colour black
Product weight [g] 15
Information about operating and control medium No acetyleneNo oxygen
