Description
Design For T-slot
Permission RCM markc UL us – Listed (OL)
CE certificate (see declaration of conformity) to EU EMC directive
KC-mark KC-EMV
Certified awarding point UL E232949
Material information halogen freeRoHs compliant
Measured parameter Position
Measurement principle Hall magnetic
Recording range [??m] <= 52 mm
ambient temperature [??C] -40 to 80
Sampling interval type [ms] 2
Max. movement speed [m/s] 3
Resolution travel [mm] <= 0,02 mm
Repeatability [mm] 0,2
Control output 2x PNP or 2x NPN adjustable
Switching element function Opener/closer switchable
Switch on time [ms] < 4 ms
Switch off time [ms] < 4 ms
Max. switching frequency [Hz] 125
Max. switch off voltage DC [V] 30
Max. output current [mA] 50
Max. switching capacity DC [W] 1,5
Voltage drop [V] < 0,5 V
Linearity error typical in ?I mm ?I1 mm
Short circuit resistance yes
Overload resistant Available
Report I-portIO-Link
IO-Link, report Device V 1.1
IO-Link, profile Smart sensor profile
IO-Link, function classes Teach channelDiagnoseIdentifikationProzess Daten Variable (PDV)Schalt-Signal Kanal (SSC)
IO-Link, communication mode COM2 (38.4 kBaud)
IO-Link, SIO mode support yes
IO-Link, port type A
IO-Link, process data width IN 2 Bytes
IO-Link, process data contents IN 12 bit PDV (Positionsmesswert)4 bit SSC (Switching Signal)
IO-Link, minimum cycle time 2,5 ms
Operating voltage range DC [V] 10 to 30
residual ripple 10 %
Reverse polarity protection for all electrical connections
Electrical connection 1, connection type Cable with plug
Electrical connection 1, connection technology M8x1 A coded to EN 61076-2-104
Electrical connection 1, number of pins / wires 4
Electrical connection 1, fastening type Screw lock
Connection outlet direction along
Plug contacts material Copper alloy gold plated
Test conditions line Bending radius strength to Festo standardCable track: 5 million cycles, bending radius 28 mmTorsional strength > 300,000 cycles, ?I270??/0.1 m
Cable length [MTR] 0,3
Line properties Cable track+robot
Cable shield colour Grey
Cable sleeve material TPE-U(PUR)
Fastening type Insertable from above into the slotPermanently screwed
installation position arbitrary
Product weight [g] 9,5
Housing material High-alloyed stainless steelsPA reinforced
Locking nut material Nickel-plated brass
Switching status indicator LED yellow
Status display LED red
Setting options IO-Linkkapazitive Taste
Ambient temperature for moving cable placements [??C] -20 to 70
Protection category IP65IP68
