Introduction to CMMT-AS-C2-11A-P3-MP-S1　FESTO Linear Drive

The FESTO DFPI-250–ND2P-E-P-G linear drive is a high-performance industrial device designed in accordance with ISO 15552 standards, suitable for various hydraulic and pneumatic control systems. This drive employs advanced technological features and high-quality materials, providing users with stable and reliable operational solutions.

Key Features and Specifications:

• Drive Specification: 250
• Stroke Length: Adjustable from 40 mm to 990 mm
• Piston Diameter: 250 mm
• Buffering: Buffer-free
• Mounting Method: Mounting plate secured with screws
• Mounting Position: Free convection, vertical
• Product Weight: 2100 g

Display and Operation:

• LED Display: Green/Yellow/Red
• Operator Control Device: Optional CDSB human-machine interface

Compliance with Standards and Certifications:

• Compliant Standards: EN 61800-3, EN 61800-5-1, EN 61800-5-2, EN ISO 13849-1
• Based on Standards: EN 50581, EN 60204-1, EN 61508-1 to EN 61508-7, EN 61800-2, EN 62061
• Certifications: RCM Trademark, TÜV Germany, c UL us Certification (OL), KC Mark, KC-EMV, CE Certification (Compliance with EU Electromagnetic Compatibility Directive, Machinery Directive, RoHS Directive), Compliance with UK EMC Directive, Machinery Regulations, and RoHS Directive

Environmental Adaptability and Durability:

• Storage Temperature: -25°C to 55°C
• Operating Temperature: 0°C to 50°C
• Operating Temperature Note: Power reduction by 3% for every 1°C rise above 40°C
• UL Environment Temperature: 0°C to 40°C
• Relative Air Humidity: 5% to 90%, non-condensing
• Maximum Installation Height: 2000 m, starting from 1000 m, power reduction of 1% per 100 m increase

Protection Level and Safety Performance:

• Protection Level: IP20
• Overvoltage Category: III
• Pollution Degree: 2
• Surge Immunity: 6 kV

Electrical Parameters:

• Nominal Voltage: Three-phase, AC 400 V
• Allowed Voltage Fluctuation: +/- 10%
• Input Voltage Range: AC 200 V to 480 V
• Power Frequency: 48 Hz to 62 Hz
• Nominal Current: 2 A, Peak Current 6 A
• Active PFC: No
• Power Supply Type: TN, IT
• Nominal Voltage: DC Load Voltage 560 V, Allowed Load Power Range +/- 10%

Control and Communication Interfaces:

• Supports Fieldbus Interfaces: EtherCAT®, EtherNet/IP, Modbus/TCP, PROFINET IRT, PROFINET RT
• Supports Encoder Interfaces: BiSS-C, EnDat®2.1/2.2, Hiperface-Geber, SIN/COS
• Features high-speed logic inputs and outputs, as well as analog inputs and outputs
• Supports various safety functions, including safety brake control and safety stop

CMMT-AS- -3A-..
CMMT-AS- -11A-P3-..
CMMT-AS-C2-3A-EC-S1
CMMT-AS-C2-3A-EP-S1
CMMT-AS-C2-3A-PN-S1
CMMT-AS-C2-11A-P3-EC-S1
CMMT-AS-C2-11A-P3-EP-S1
CMMT-AS-C2-11A-P3-PN-S1
CMMT-AS-C3-11A-P3-EC-S1
CMMT-AS-C3-11A-P3-EP-S1
CMMT-AS-C3-11A-P3-PN-S1
CMMT-AS-C4-3A-EC-S1
CMMT-AS-C4-3A-EP-S1
CMMT-AS-C4-3A-PN-S1
CMMT-AS-C5-11A-P3-EC-S1
CMMT-AS-C5-11A-P3-EP-S1
CMMT-AS-C5-11A-P3-PN-S1
CMMT-AS-C7-11A-P3-EC-S1
CMMT-AS-C7-11A-P3-EP-S1
CMMT-AS-C7-11A-P3-PN-S1
CMMT-AS-C12-11A-P3-EC-S1
CMMT-AS-C12-11A-P3-EP-S1
CMMT-AS-C12-11A-P3-PN-S1
CMMT-ST-C8-1C-EC-S0
CMMT-ST-C8-1C-EP-S0
CMMT-ST-C8-1C-PN-SO
