VABM-L1-10HWS1-G18-4-GR SMC Pneumatic Manifold: Precision Manufacturing, Efficient Layout

2024-07-19 By xyj2024 0

In automated control systems, the pneumatic manifold plays a crucial role in the distribution and control of compressed air, significantly impacting the performance and reliability of the entire system. SMC, a leading global manufacturer of pneumatic components, introduces the VABM-L1-10HWS1-G18-4-GR pneumatic manifold. With its fine grid size and high standard of corrosion resistance, it meets the strict requirements of industrial automation for pneumatic distribution.

Product Overview

SMC’s VABM-L1-10HWS1-G18-4-GR pneumatic manifold is designed for efficient pneumatic control, offering a compact design and high-precision manufacturing process, making it an ideal pneumatic component for automated systems.

Core Features

  1. Fine Grid Size:
    • A grid size of 10.5 mm provides more flexible layout options and more efficient space utilization.
  2. Diverse Mounting Positions:
    • Mounting positions are optional, facilitating integration into various automated devices and machines.
  3. Maximum Valve Position Quantity:
    • Supports up to 4 valve positions, catering to different control needs.
  4. International Certification:
    • Certified by c UL us – Certification (OL), ensuring the safety and reliability of the product.
  5. Corrosion Resistance:
    • Corrosion resistance level is CRC 2, with medium corrosion resistance, suitable for use in various environments.
  6. Paint Wetting Defect Substance (PWIS) Compliance:
    • Compliant with VDMA24364-B1/B2-L standards, ensuring the quality and durability of the product’s surface treatment.
  7. Wide Storage Temperature Range:
    • Can be stored in a temperature range of -20°C to 60°C, suitable for different storage conditions.
  8. Various Pneumatic Interfaces:
    • Offers various pneumatic interface sizes and types, including G1/8, M5, M7, etc., making it convenient to connect with various pneumatic components.
  9. RoHS Compliant Materials:
    • The material of the pneumatic manifold is refined aluminum alloy, compliant with RoHS standards, environmentally friendly, and durable.

Technical Specifications

  • Grid Size: 10.5 mm
  • Mounting Position: Optional
  • Maximum Valve Position Quantity: 4
  • Certification: c UL us – Certification (OL)
  • Corrosion Resistance Level: CRC 2
  • PWIS Compliance: VDMA24364-B1/B2-L
  • Storage Temperature: -20°C … 60°C
  • Pilot Air Port: 12/14, M5
  • Pilot Exhaust Port: 82/84, M5
  • Pneumatic Interface, Port 1: G1/8
  • Pneumatic Interface, Port 2: M7
  • Pneumatic Interface, Port 3: G1/8
  • Pneumatic Interface, Port 4: M7
  • Pneumatic Interface, Port 5: G1/8
  • Material: RoHS compliant, refined aluminum alloy

Application Scenarios

SMC VABM-L1-10HWS1-G18-4-GR pneumatic manifold is suitable for the following fields:

  • Industrial automation equipment
  • Robotic control systems
  • Pneumatic workstations
  • Precision instrument manufacturing
  • Any situation requiring precise pneumatic control

Its precise manufacturing process and diverse interface options make it excellent in the field of automated control.

SMC’s VABM-L1-10HWS1-G18-4-GR pneumatic manifold, with its fine grid size, diverse mounting options, and high standard of corrosion resistance, is an ideal pneumatic control solution in the field of industrial automation. Whether in automated equipment or in precise pneumatic control systems, this pneumatic manifold provides stable and reliable performance. Choose SMC for precision and efficiency.
