LFMA-3/8-D-MINI-DA-A FESTO Ultra-Fine Filter: Efficient Filtration, Pure Supply

In the fields of industrial automation and precision engineering, clean compressed air is key to ensuring equipment operates correctly and to enhancing production efficiency. FESTO, a global leader in pneumatic component manufacturing, has introduced the LFMA-3/8-D-MINI-DA-A ultra-fine filter. This product meets the high standards of industrial applications with its superior filtration performance and reliability.

Product Overview

The LFMA-3/8-D-MINI-DA-A from SMC is designed to provide ultra-fine filtration. It uses advanced fiber filtration technology to ensure the output air quality meets the highest standards.

Core Features

• High-Efficiency Filtration: With a filtration rating of 0.01 µm, it effectively removes minute particles from compressed air.
• Automatic Condensate Drain: Equipped with an automatic condensate drain, reducing maintenance needs and improving system efficiency.
• High Filtration Efficiency: A filtration efficiency of up to 99.9999% ensures the purity of the output air.
• Metal Protective Cover: Comes with a metal protective cover for enhanced durability and protection.
• Medium Corrosion Resistance: The corrosion resistance level is CRC 2, suitable for various working environments.
• RoHS Compliant Materials: All materials are RoHS compliant, environmentally friendly, and safe.

Technical Specifications

• Series: D
• Specification: Mini
• Filtration Rating: 0.01 µm
• Condensate Drain Device: Fully automatic
• Symbol: 00991544
• Working Pressure: 2 bar … 12 bar
• Working Media: Compressed air, compliant with ISO 8573-1:2010 [6:8:4]; Inert gases
• Outlet Air Purity Level: Compressed air, compliant with ISO 8573-1:2010 [1:7:2]; Inert gases
• Maximum Standard Flow Rate for Clean Air Grade: 450 l/min
• Minimum Standard Flow Rate for Clean Air Grade: 100 l/min
• Protective Cover: Metal protective cover
• Corrosion Resistance Class: CRC 2
• PWIS Compliance: VDMA24364-B1/B2-L
• Medium Temperature: 1.5 °C … 60 °C
• Ambient Temperature: -10 °C … 60 °C
• Residual Oil Content: 0.01 mg/m³
• Differential Pressure Indicator: Graphical display
• Installation Method: Tubular installation or with accessories
• Installation Position: Vertical +/-5°
• Air Port, Port 1: G3/8
• Air Port, Port 2: G3/8
• Housing Material: Die-cast zinc
• Filter Material: Borosilicate fiber
• Bowl Cover Material: PC
• Product Weight: 368 g

Application Scenarios

• Industrial Automation Equipment: Provides clean compressed air for automated machinery and systems.
• Precision Engineering: Used in precision machining and measurement requiring high-purity air.
• Medical Equipment: Provides clean air for medical equipment requiring a sterile environment.

The FESTO LFMA-3/8-D-MINI-DA-A ultra-fine filter is an ideal choice in the fields of industrial automation and precision engineering with its efficient filtration performance and reliable quality. Whether in automated equipment or precision engineering, this filter provides stable and pure air quality. Choose FESTO for purity and efficiency.
