DACS-25-A-S FESTO brake: High-Performance Clamping System, a Reliable Choice for Industrial Automation

2024-07-23 By xyj2024 0

In the field of industrial automation, the performance of clamping systems directly affects production efficiency and product quality. The FESTO DACS-25-A-S braking system has become an indispensable component in automated machinery with its excellent performance and reliability.

Product Overview

The FESTO DACS-25-A-S is a high-performance clamping system suitable for a variety of applications requiring precise control and high safety standards. Its design takes into account easy installation, maintenance, and durability to ensure stable operation in various industrial environments.

Technical Features

  • Optional Installation Position: Provides flexible installation options to adapt to different mechanical structures and layout requirements.
  • Clamping Type and Direction: Dual-sided clamping with spring force for clamping and release, making operation simple and convenient.
  • Position Detection: Position detection is achieved through a proximity switch, improving the system’s response speed and accuracy.
  • Safety Features: Equipped with functions to pause and stop motion, ensuring operational safety.
  • Performance Level (PL): Meets the high safety standards of stop, brake, prevent motion/Category 1, Performance Level c.

Performance Specifications

  • Working Pressure: 0.38 Mpa to 0.8 Mpa (3.8 bar to 8 bar, 55.1 psi to 116 psi), accommodating a wide range of working pressure requirements.
  • Maximum Allowable Test Pressure: 8 bar, ensuring the system’s stability under high pressure.
  • Minimum Release Pressure: 3.8 bar, guaranteeing the reliability of the clamping force.
  • Round Material to Be Clamped: Diameter 25 mm, suitable for workpieces of various diameters.
  • Certification: CE certified by TÜV, complying with the EU Machinery Directive and UK machinery regulations.

Material and Environmental Adaptability

  • Working Medium: Compressed air, compliant with ISO 8573-1:2010 [7:4:4], ensuring clean and stable air supply.
  • Corrosion Resistance Class CRC: Level 1, with low corrosion resistance, suitable for general industrial environments.
  • Paint Wetness Indicator Substance (PWIS) Compliance: VDMA24364-B2-L, ensuring the product’s corrosion resistance in specific environments.
  • Ambient Temperature: -10 °C to 80 °C, adaptable to a wide range of temperature changes.
  • Static Clamping Force: 8200 N, providing a strong clamping force to ensure stable workpiece holding.

Application Scenarios

The FESTO DACS-25-A-S braking system is suitable for:

  • Automated Assembly Lines: Providing stable clamping and release during the automated assembly process.
  • Machining: Fixing workpieces during machining to improve accuracy.
  • Packaging Machinery: Stabilizing packaging materials during the packaging process to increase efficiency.
  • Robotics: As a gripping tool for robot arms, achieving precise operations.

The FESTO DACS-25-A-S braking system is an ideal choice in the field of industrial automation with its high performance, safety, and adaptability to various applications. Its excellent performance and reliability ensure stable operation in a variety of industrial applications. For more information or to discuss its integration into your system, please visit the FESTO official website or contact their customer service.
