HSW-10-AS-SD FESTO High-Speed Gripping Module: Precision Choice for Efficient Automation

In today’s rapidly developing field of automation technology, high-speed gripping modules have become key equipment for improving production efficiency and achieving precise operations. The HSW-10-AS-SD high-speed gripping module introduced by FESTO Corporation meets the demands of industrial automation for high-speed and high-precision tasks with its exceptional performance and sophisticated design.

Extensive Working Stroke

The HSW-10-AS-SD module offers a working stroke of 9mm to 15mm, combined with a maximum linear stroke of 90/90mm at a 90° swing angle and a Z-stroke of 80mm to 100mm, capable of adapting to various job requirements.

Efficient Driving Performance

The driving shaft design with a linear guide and ball bearings ensures smooth and accurate motion, while the forced pilot working motion sequence improves operational response speed.

Precise Position Detection

Position detection via proximity switches achieves a repeatability of ±0.02mm at the end position, ensuring the accuracy of operations.

Noise-Reducing Buffer Design

The built-in buffer effectively reduces noise, enhancing the comfort of the working environment and protecting the mechanical structure.

Flexible Installation Options

The module’s installation position is optional and supports installation through holes and positioning sleeves, providing convenience and flexibility in installation.

Strong Load Capacity

The maximum effective load reaches 0.5 kg, the driving shaft can withstand a maximum radial force of 30 N, and the maximum process force in the Y direction is also 30 N, meeting a variety of load requirements.

Materials and Surface Treatments

• Driving shaft: Linear guide with ball bearings
• Block, spring pressure parts, adjustment screws: High-alloy steel
• Cover, base plate, bracket, grid: Refined aluminum alloy, anodized
• Cross guide: Tempered steel
• Swing lever: Surface-hardened steel
• Slotted guide plate, sensor guide: Refined aluminum alloy, anodized

Technical Parameters Overview

• Working Stroke: 9 mm … 15 mm
• Specification: 10
• Maximum Linear Stroke at 90° Swing Angle: 90/90 mm
• Z-Stroke: 80 mm … 100 mm
• Ambient Temperature: 0 °C … 60 °C
• Maximum Driving Torque of the Driving Shaft: 0.85 Nm
• Maximum Torque Mx/My/Mz: 0.6 Nm
• Product Weight: 1300 g

Application Scenarios

The HSW-10-AS-SD high-speed gripping module is suitable for the following fields:

• Packaging and sorting automation
• Electronics assembly lines
• Food processing industry
• Pharmaceutical automation production lines

The HSW-10-AS-SD high-speed gripping module from FESTO, with its efficiency, precision, low noise, and strong load capacity, has become a preferred solution in the field of industrial automation. Choose FESTO for an efficient and reliable automation partner.
