MH-2-230VAC-PA FESTO Solenoid Coil: High Efficiency, High Reliability

In the field of industrial automation, the solenoid coil, as a core component of the actuator, directly affects the response speed and stability of the entire control system. The MH-2-230VAC-PA solenoid coil introduced by FESTO, with its efficient power conversion and stable continuous duty capability, provides strong driving support for automated control systems.

Product Features

• Optional Installation Position: Offers flexible installation options to adapt to various application scenarios.
• Shortest Grasping Time: A rapid response of 12 milliseconds ensures the system’s efficient performance.
• Continuous Duty Rating of 100%: Suitable for long-term operation in industrial environments, ensuring the continuous working capability of the solenoid coil.
• Compliance with International Standards: CE certified, compliant with the EU Low Voltage Directive, ensuring the product’s safety and reliability.

Technical Specifications

• Power Factor: 0.7, ensuring efficient energy conversion of the solenoid coil.
• Coil Characteristics: Consumes 14.0 VA at 230V AC voltage.
• Tolerance to Frequency and Voltage Fluctuations: Allows ±10% fluctuations in both frequency and voltage, enhancing the adaptability of the solenoid coil.
• Protection Rating: IP65, providing good dust and water protection.
• Ambient Temperature Range: Suitable for a wide temperature range of -20°C to 50°C, ensuring stable operation in various environments.
• Maximum Fastening Torque for Installation: 2 Nm, used for fastening operations during installation to ensure the secure mounting of the solenoid coil.

Material Description

• Solenoid Coil Materials: Made of thermosetting plastics, copper, and steel to ensure the durability and reliability of the coil.
• RoHS Compliance: All materials meet RoHS standards, ensuring environmental friendliness and safety.

Application Scenarios

The MH-2-230VAC-PA solenoid coil is suitable for driving various pneumatic actuator elements such as pneumatic valves and cylinders, widely used in fields like automated machinery, robotics, and precision control equipment.

With its high efficiency, high reliability, and rapid response, the FESTO MH-2-230VAC-PA solenoid coil has become an ideal choice in the field of industrial automation. Choosing FESTO means selecting professional and efficient components for automated control.
