Product Overview

The DXT170-71-1 is an industrial-grade high-strength socket-type tube connector, featuring an innovative snap-fit connection structure designed for hydraulic and pneumatic pipeline systems. This product enables quick plug-and-play installation, significantly improving the installation efficiency and maintenance convenience of pipeline systems

Product Features

• Quick-Connection Design
  • Patented snap-fit connection mechanism allows one-handed installation and disassembly.
  • 360° rotatable joint design eliminates pipeline torque.
  • Self-locking function ensures connection reliability.
• High-Performance Structure
  • Rated working pressure: 35MPa.
  • Stainless steel 316 main body material.
  • Corrosion-resistant and wear-resistant design.
• Excellent Sealing Performance
  • Double O-ring sealing structure.
  • Leakage rate < 0.1ml/min.
  • Temperature resistance range: -40℃ to +120℃.
• Diversified Configurations
  • Multiple pipe diameter specifications available.
  • Provides straight, right-angle, tee, and other types.
  • Optional version with pressure relief valve.

Technical Parameters

Application Fields

• Construction Machinery
  • Excavator hydraulic pipelines
  • Crane hydraulic systems
• Industrial Equipment
  • Injection molding machine hydraulic circuits
  • Die-casting machine pipeline connections
• Energy Sector
  • Wind power hydraulic systems
  • Oil drilling equipment
• Special Applications
  • Hydraulic connections for military equipment
  • Marine hydraulic pipelines

Product Advantages

• Installation Advantages
  • Reduces installation time by 80%.
  • No special tools required.
  • Supports blind plug connection.
• Maintenance Advantages
  • Quick disassembly reduces downtime.
  • Seals can be replaced individually.
  • Maintenance-free design.
• Performance Advantages
  • Strong high-pressure tolerance.
  • Excellent anti-vibration performance.
  • Long service life.
• Economic Advantages
  • Lowers installation labor costs.
  • Reduces maintenance expenses.
  • Improves equipment utilization.

Summary

The DXT170-71-1 socket-type tube fitting revolutionizes traditional hydraulic and pneumatic pipeline connections through innovative quick-connection technology. It not only addresses the pain points of complex and time-consuming installation in traditional flange and threaded connections but also ensures system reliability with its excellent sealing performance and high-pressure tolerance. In the context of shorter maintenance cycles and higher efficiency requirements for industrial equipment, the DXT170-71-1 socket-type tube fitting has become an ideal connection solution for modern hydraulic and pneumatic systems, thanks to its convenient installation features and superior performance. This product is particularly suitable for applications requiring frequent disassembly/maintenance or facing limited on-site installation conditions, providing more efficient and reliable pipeline connection options for construction machinery, industrial equipment, energy equipment, and other fields. With the intelligent and modular development of industrial equipment, the DXT170-71-1 socket-type tube fitting will embrace a broader application prospect.
