Product Report on CQSB16 – 30DM Pneumatic Cylinder
2025-07-041. Product Overview
1.1 Product Introduction
The CQSB16 – 30DM is a compact and reliable standard pneumatic cylinder widely used in automation machinery, light industrial equipment, textile machinery, and other industrial applications. Powered by compressed air, it converts pneumatic energy into mechanical linear motion, delivering stable and precise actuation for automated systems.
1.2 Product Positioning
Designed for medium-to-low load applications requiring space-saving layouts and high-precision linear motion, this cylinder offers an economical, easy-to-install, and low-maintenance solution for diverse automation needs.
2. Key Features
2.1 Compact & Lightweight Design
- Optimized for minimal space occupancy, enabling flexible integration in tight spaces.
- Ideal for equipment miniaturization and modular designs.
2.2 High-Precision Motion Control
- Precision-machined barrel and piston with tight tolerances reduce air leakage.
- Smooth operation with low repeatability error, suitable for high-accuracy automation tasks.
2.3 Durability & Reliability
- Aluminum alloy barrel: Lightweight, corrosion-resistant, and long-lasting.
- Hardened piston rod and surface-treated components enhance wear resistance for continuous operation.
2.4 Easy Installation & Maintenance
- Multiple mounting options: Basic, flange, or clevis mounting.
- Simplified maintenance: Routine lubrication and seal checks ensure longevity.
2.5 Broad Operational Adaptability
- Pressure range: 0.1–0.7MPa.
- Temperature range: -10°C to 60°C, suitable for harsh industrial environments.
3. Technical Specifications
| Parameter | Value |
|---|---|
| Bore Size | 16mm |
| Stroke | 30mm |
| Pressure Range | 0.1–0.7MPa |
| Speed Range | 50–500mm/s |
| Buffering | Rubber cushioning |
4. Working Principle
- Extension: Compressed air enters the non-rod side, pushing the piston forward (rod extends).
- Retraction: Air shifts to the rod side, retracting the piston.
- Direction, speed, and force are controlled via airflow/pressure adjustment.
5. Applications
5.1 Automated Production Lines
- Used for pick-and-place, positioning, and assembly in electronics, automotive, and food industries.
5.2 Light Industrial Machinery
- Drives actuators in packaging, printing, and sealing equipment.
5.3 Textile Machinery
- Controls fabric tension, weaving, and winding motions with precision and stability.
6. Competitive Advantages
6.1 Space Efficiency
- Compact design saves installation space; versatile mounting options simplify integration.
6.2 Performance Reliability
- Consistent accuracy and low failure rates ensure uninterrupted production.
6.3 Cost-Effectiveness
- Low maintenance and long service life reduce total ownership costs.
7. Conclusion
The CQSB16 – 30DM cylinder excels in precision, durability, and adaptability, making it a trusted choice for automation, light industry, and textile applications. Its space-saving design, reliable performance, and ease of maintenance deliver exceptional value for industrial automation systems.
Key Phrases:
- “Precision linear motion”
- “Corrosion-resistant aluminum construction”
- “Plug-and-play installation”
- “Low total cost of ownership (TCO)”
