ADNGF-20-20-P-A

ADNGF-20-20-P-A

$119.35

Compact Cylinder is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:ADNGF-20-20-P-A

FESTO Order Number:554223

SKU: ADNGF-20-20-P-A Category: Tag:

Description

Stroke [mm] 20
Piston diameter 20 mm
Based on standard ISO 21287
Dampening P: Elastic silencer rings / plates double-sided
installation position arbitrary
Construction set up Pistonpiston rodprofile tube
Position detection For proximity switch
Anti-twist lock / guide Guide rod with yoke
Operating pressure [bar] 1.5 to 10
Principle of operation double acting
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Corrosion resistant class KBK 2 – moderate corrosion stress
ambient temperature [??C] -20 to 80
Impact energy at the end positions [J] 0,20
Theoretical force at 6 bar, Return flow [N] 141
Theoretical force at 6 bar, flow [N] 188
Moving mass at 0 mm stroke [g] 60
Weight supplement per 10 mm stroke [g] 26
Base weight at 0 mm stroke [g] 161
Supplement moved mass per 10 mm stroke [g] 11
Pneumatic connection M5
Material information RoHs compliant
Cover material aluminiumanodized
Seals material TPE-U(PUR)
Piston rod material High-alloyed steel
Cylinder tube material Aluminium wrought alloySmooth anodised
