Home » Products » CPV10-GE-DI02-8

CPV10-GE-DI02-8

CPV10-GE-DI02-8

$671.69

Electrical Interface is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:CPV10-GE-DI02-8

FESTO Order Number:546188

SKU: CPV10-GE-DI02-8 Category: Tag:

Description

Reverse polarity protection for all electrical connections
Baud rate 9,6 kBaud … 12 MBaudautomatische Erkennung
Nominal operating voltage DC [V] 24
Corrosion resistant class KBK 1 – low corrosion stress
Bearing temperature [??C] -20 to 70
Protection category IP65
ambient temperature [??C] -5 to 50
LED display bus specific BUS: Communication and configuration error
LED display product specific 12/14: Valve switching statusPOWER: Operating voltage electronics and load supply
Cover material PA reinforced
Material information RoHs compliant
CP strand expansion 32 outputsyes32 inputs
Fieldbus interface wahlweise:Sub-D, 9-polig, DoseDose und Stecker, M12x1, 5-polig, B-codiert
Device specific diagnosis Missing module on the CP strand expansionShort circuit / overload outputsUnder-voltage Outputs:Under-voltage Sensor supplyUnder-voltage ValveVia device related diagnosis (DPV0)
Communication types Cyclical communication
Configuration support GSD file and bitmaps
Max. number of valve coils with strand expansion 48
Max. number of valve coils 16
Operating voltage range DC [V] 20.4 to 26.4
Max. number of outputs 16 valve coils and 32 outputs48 valve flushing
Max. number of inputs 32
Power blackout bridging [ms] 10
residual ripple 4 Vss
Power input in nominal operating voltage load Valve type dependent
Power input in nominal operating voltage Sensor supply: Sensor dependentElectronics: <= 100 mA Permission c UL us - Recognized (OL) Addressing area 1 ... 125Setting by switching module Fieldbus certification PNO Galvanic separation fieldbus interface Opto-coupler Product identification Product family: 4: Valve Seals material CRNBR Housing material Aluminium die casting
