CPX-8DA-H

CPX-8DA-H

$245.33

Output Module is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:CPX-8DA-H

FESTO Order Number:550204

SKU: CPX-8DA-H Category: Tag:

Description

Dimensions W x L x H 50 mm x 107 mm x 50 mm(Incl. linking block and connectors)
Diagnosis Unterspannung Ausg?ngeKurzschluss/??berlast pro Kanal
Parameterising Failsafe pro KanalForcen pro KanalIdle Mode pro Kanal??berwachung ModulVerhalten nach Kurzschluss
LED displays 1 Sammeldiagnose8 Kanaldiagnose8 Kanalstatus
Operating voltage range DC [V] 18 to 30
Intrinsic power input at operating voltage Type 34 mA
Max. power supply per channel 2.1 A (50 W lamp load), per channel pair
Nominal operating voltage DC [V] 24
Potential separation channel – internal bus Yes, for intermediate feed
Potential separation channel – channel no
Corrosion resistant class KBK (In integrated condition)1 – low corrosion stress
Bearing temperature [??C] -20 to 70
Protection category Depends on connection block
ambient temperature [??C] -5 to 50
Product weight [g] 48,0
Housing material PCPA reinforced
Fuse (short circuit) Internal electronic fuse Per channelAdditional fuse
Quantity outputs: 8
Max. cumulative current outputs per module [A] 8,4
Characteristic curves outputs Depending on IEC1131-T2
Switching logic outputs PNP (Positive switching)
