Home » Products » CPX-M-FB34

CPX-M-FB34

CPX-M-FB34

$899.21

Bus Node is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:CPX-M-FB34

FESTO Order Number:548751

SKU: CPX-M-FB34 Category: Tag:

Description

Dimensions W x L x H 50 mm x 107 mm x 80 mm(Incl. linking block)
Parameterising SystemparameterFailsafe-ReaktionDiagnoseverhaltenForcen von Kan?lenSignal-Setup
Additional functions Fast start up (FSU)Acyclical data access via FieldbusAcyclical data access via EthernetStart-up parameterisation in text via field busSystem status can be shown from process datAdditional diagnosis interface for control panelChannel related diagnosis via fieldbus
Operating element DIL switchOptional storage card
Operating voltage range DC [V] 18 to 30
Intrinsic power input at operating voltage Type 120 mA
Nominal operating voltage DC [V] 24
Corrosion resistant class KBK 0 – No corrosion stressing
Bearing temperature [??C] -20 to 70
Protection category IP65IP67
ambient temperature [??C] -5 to 50
Product weight [g] 280,0
Max. address volume outputs [Byte] 64
Max. address volume inputs [Byte] 64
Report PROFINET IRTPROFINET RT
Housing material Aluminium die casting
Fieldbus interface 2x Socket RJ45 push-pull, AIDA
Device specific diagnosis Unterspannung ModuleDiagnose-SpeicherKanal- und modulorientierte Diagnose
Configuration support GSDML file
Baud rate 100 Mbit/s
LED display bus specific M/P: Maintenance / PROFlenergyNF: Network errorTP1: Network active port 1TP2: Network active port 2
LED display product specific PL: Load supplySF: System errorM: Modify, parameterisationPS: Electronics supply, sensor supply
