Description
Dimensions W x L x H 40 mm x 91 mm x 50 mm
Pitch dimension [mm] 40
Fastening type auf Elektrik-Anschaltungauf Elektrik-Anschlussplatte
Product weight [g] 90
Report As interface
Fieldbus interface As interface
Fieldbus interface, report As interface
Fieldbus interface, connection type Plug
Fieldbus interface, connection technology M12x1 A coded to EN 61076-2-101
Fieldbus interface, number of pins / wires 4
Internal cycle time 10 ms
Max. address volume inputs [Byte] 2
Max. address volume outputs [Byte] 2
Diagnosis UnterspannungKommunikationsfehlerSystemdiagnose
Parameterising Watchdog disableWatchdog enable
Operating element DIL switch
LED display product specific PS: Operating voltage electronics and load supplyX1: System status module I port 1
LED display bus specific AS-i: As interface Operation
Operating voltage range DC [V] 20 to 31.6
Nominal operating voltage DC [V] 30
Intrinsic power input at operating voltage Type 50 mA
Max. power supply [A] 4,0
Permission c UL us – Listed (OL)
CE certificate (see declaration of conformity) to EU EMC directive
Corrosion resistant class KBK 2 – moderate corrosion stress
Bearing temperature [??C] -20 to 70
Protection category IP65IP67
Information about protection category in assembled conditionunused connection closed
ambient temperature [??C] -5 to 50
Housing material PA
Material information LABS containing materials includedRoHs compliant
Fieldbus interface 2, function Voltage supplyBus connector forwarding
Fieldbus interface 2, connection type socket / container / ??.
Fieldbus interface 2, connection technology M12x1 A coded to EN 61076-2-101
Fieldbus interface 2, number of pins / wires 4
Configuration support none
