DAPZ-SB-M-250AC-DR-AR

DAPZ-SB-M-250AC-DR-AR

$245.84

Limit Switch is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:DAPZ-SB-M-250AC-DR-AR

FESTO Order Number:534474

SKU: DAPZ-SB-M-250AC-DR-AR Category: Tag:

Description

Permitted cable diameter [mm] 7 to 13
Based on standard EN 60947-5-1VDI/VDE 3845 (NAMUR)
Design round
installation position arbitrary
Short circuit resistance no
Switching element function changeover contact
Reverse polarity protection no
Measurement principle Mechanical / electrical
Switching position display yes
Operating voltage range AC [V] 4 to 250
Operating voltage range DC [V] 4 to 250
Intrinsic power input at operating voltage [mA] 1 to 5000
Insulation voltage [V] 250
Max. output current [mA] 5.000
Minimum load current 1 mA at 4 V/DC
Surge voltage strength [kV] 2,5
Degree of contamination 3
CE certificate (see declaration of conformity) to EU low voltage directive
Corrosion resistant class KBK 2 – moderate corrosion stress
Protection category IP67
ambient temperature [??C] -20 to 70
Electrical connection Screw clamp
Cable screwing M20x1,5
Material information RoHs compliant
Seals material NBR
Housing cover material PC
Housing socket material ABS+PC
Console material ABS+PC
