DSM-16-270-P1-FW-A-B

DSM-16-270-P1-FW-A-B

$417.64

Semi-Rotary Drive is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:DSM-16-270-P1-FW-A-B

FESTO Order Number:566206

SKU: DSM-16-270-P1-FW-A-B Category: Tag:

Description

size 16
Dampening angle [deg] 9,0
Settings range swivel angle [deg] 0 to 246
Swivel angle [deg] 0 to 246
Dampening P1: Elastic silencer rings / plates double-sided With fixed limit stop
installation position arbitrary
Fine adjustment [deg] -6
Principle of operation double acting
Construction set up Rotary vane
Position detection For proximity switch
Operating pressure [bar] 1.8 to 10
Max. swivel frequency at 6 bar [Hz] 2,0
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]
Corrosion resistant class KBK 0 – No corrosion stressing
ambient temperature [??C] -10 to 60
Max. axial force [N] 30
Max. radial force [N] 75
Theoretical torque at 6 bar [Nm] 2,50
Permitted mass moment of inertia [kg/m2] 0,03000
Product weight [g] 515
Fastening type with female thread
Pneumatic connection M5
Material information Copper and PTFE-freeRoHs compliant
Drive shaft material Nickel-plated steel
Seals material TPE-U(PU)
Housing material Aluminium wrought alloy
