Home » Products » EAGF-V2-KF-100-100

EAGF-V2-KF-100-100

$1,871.41

Guide Unit is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:Eagf-V2-Kf-100-100

FESTO Order Number:1725850

SKU: EAGF-V2-KF-100-100 Category: Tag:

Description

size 100
Stroke [mm] 100
Reversing play [??m] 0
installation position arbitrary
Guide ball guide
Construction set up Guide
Corrosion resistant class KBK 0 – No corrosion stressing
ambient temperature [??C] -20 to 80
Max. force Fy [N] 2.300
Max. force Fy static [N] 3.120
Max. force Fz [N] 2.300
Max. force Fz static [N] 3.120
Max. torque Mx [Nm] 198
Max. torque Mx static [Nm] 268
Max. torque My [Nm] 197
Max. torque My static [Nm] 267
Max. torque Mz [Nm] 197
Max. torque Mz static [Nm] 267
Pushing force [N] 40,0
Moving mass [g] 6.892
Product weight [g] 14.023
Centre of mass of the moved mass at 0 mm stroke [mm] 47
Supplement centre of mass of the moved mass per 10 mm stroke [mm] 3,6
Fastening type with female thread
Material information Copper and PTFE-freeRoHs compliant
Guide element material Quenched and tempered steel
Housing material Aluminium wrought alloyanodized
Joch plate material Steel
