Description
size 100
Stroke [mm] 320
Reversing play [??m] 0
installation position arbitrary
Guide ball guide
Construction set up Guide
Corrosion resistant class KBK 0 – No corrosion stressing
ambient temperature [??C] -20 to 80
Max. force Fy [N] 2.300
Max. force Fy static [N] 3.120
Max. force Fz [N] 2.300
Max. force Fz static [N] 3.120
Max. torque Mx [Nm] 198
Max. torque Mx static [Nm] 268
Max. torque My [Nm] 197
Max. torque My static [Nm] 267
Max. torque Mz [Nm] 197
Max. torque Mz static [Nm] 267
Pushing force [N] 40,0
Moving mass [g] 8.586
Product weight [g] 15.695
Centre of mass of the moved mass at 0 mm stroke [mm] 47
Supplement centre of mass of the moved mass per 10 mm stroke [mm] 3,6
Fastening type with female thread
Material information Copper and PTFE-freeRoHs compliant
Guide element material Quenched and tempered steel
Housing material Aluminium wrought alloyanodized
Joch plate material Steel
