Home » Products » EGSC-BS-KF-60-100-12P

EGSC-BS-KF-60-100-12P

$903.06

Mini Slide is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:Egsc-Bs-Kf-60-100-12P

FESTO Order Number:4356469

SKU: EGSC-BS-KF-60-100-12P Category: Tag:

Description

Working stroke [mm] 100
size 60
Stroke reserve [mm] 0
Reversing play [??m] 150
Spindle diameter [mm] 12
Spindle pitch [mm/U] 12
installation position arbitrary
Guide ball guide
Construction set up Electrical mini-carriageswith ball screw drive
Motor type Step motorServo motor
Referencing Fixed stopper block negativeFixed stopper block positiveReference switch
Spindle type Ball screw drive
Position detection For proximity switch
Max. acceleration [m/s2] 15
Max. speed [m/s] 0,6
Repeatability ?I0.015 mm
Power-on time 100 %
Corrosion resistant class KBK 0 – No corrosion stressing
Sound level [dB(A)] 55
Protection category IP40
ambient temperature [??C] 0 to 50
Dynamic load factor fixed bearing [N] 13.321
Dynamic load factor linear guide [N] 13.400
Dynamic load factor ball screw drive [N] 4.600
Max. force Fy [N] 4.937
Max. force Fz [N] 4.937
Max. torque Mx [Nm] 20,00
Max. torque My [Nm] 30,00
Max. torque Mz [Nm] 30,00
Max. radial force on drive shaft [N] 420
Max. feed force Fx [N] 250
Guideline payload, horizontal [KGM] 10
Guideline payload, vertical [KGM] 10
Static load factor ball screw drive [N] 8.500
Static load factor linear guide [N] 26.900
Mass inertia JH per metre stroke [kg/cm2] 0,27076
Mass inertia JL per kg usable load [kg/cm2] 0,03648
Mass inertia JO [kg/cm2] 0,08386
Feed constant [mm/U] 12
Static load factor fixed bearing [N] 7.000
Guideline running performance [km] 5.000
Maintenance interval Lifetime lubrication
Moving mass at 0 mm stroke [g] 675
Weight supplement per 10 mm stroke [g] 95
Base weight at 0 mm stroke [g] 1.555
Product weight [g] 2.505
Supplement moved mass per 10 mm stroke [g] 40
Fastening type with female threadswith centring sleevewith accessorieswith cylinder pin
Interface code actuator T42
Material information LABS containing materials includedRoHs compliant
Carriage guide material Roller bearing steel
Guide carriage material Roller bearing steel
Housing material Aluminium wrought alloy, anodised
Joch plate material Aluminium wrought alloy, anodised
Piston rod material High-alloyed stainless steels
Carriage material Aluminium wrought alloy, anodised
Spindle nut material Roller bearing steel
Spindle material Roller bearing steel
