Description
Valve function Exhaust air flow control return function
Pneumatic connection 1 QS-8
Pneumatic connection 2 G1/4
Setting element hexagon socket
Fastening type Screwable
Normal nominal flow in one-way flow control [l/min] 0 to 450
Normal nominal flow in check valve direction [l/min] 390 to 570
ambient temperature [??C] -10 to 60
installation position arbitrary
Normal flow In one-way flow control 6 -> 0 bar [l/min] 0 to 700
Normal flow In check valve direction 6 -> 0 bar [l/min] 820 to 930
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Medium temperature [??C] -10 to 60
Product weight [g] 34,8
Material information Copper and PTFE-free
Seals material NBR
Regulation screw material PA reinforced
Swivel connection material Zinc pressure cast
Operating pressure complete temperature range [bar] 0.2 to 10
Banjo bolt material Aluminium wrought alloyanodized
Bearing temperature [??C] -10 to 40
Actuation type Manually
Nominal tightening torque [Nm] 11,0
Tolerance to nominal tightening torque ?I 10 %
Sleeve material POM
