Home » Products » HGP-16-A-B-SSK

HGP-16-A-B-SSK

HGP-16-A-B-SSK

$747.22

Parallel Gripper is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:HGP-16-A-B-SSK

FESTO Order Number:539636

SKU: HGP-16-A-B-SSK Category: Tag:

Description

size 16
Stroke per gripper jaw [mm] 5,0
Max. exchange precision [mm] 0,2
Repeatability grippers [mm] < 0,04 mm Quantity Gripper jaws 2 installation position arbitrary Gripper function Parallel Construction set up lever Position detection For proximity switch Open total gripping force at 6 bar [N] 140 Close total gripping force at 6 bar [N] 160 Operating pressure [bar] 2 to 8 Max. working frequency gripper [Hz] 4 Min. opening time a 6 bar [ms] 44 Min. closing time at 6 bar [ms] 60 Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Information about operating and control medium Oiled operation possible (required in further operations) Corrosion resistant class KBK 1 - low corrosion stress Protection category IP54 ambient temperature [??C] 5 to 60 Open gripper jaws at gripping force of 6 bar [N] 70 Close gripper jaws at gripping force at 6 bar [N] 80 Mass inertia [kg/cm2] 0,470 Max. force on gripper jaws Fz static [N] 90 Max. torque on gripper jaws Mx static [Nm] 3,3 Max. torque on gripper jaws My static [Nm] 3,3 Max. torque on gripper jaws Mz static [Nm] 3,3 Max. mass per external griper finger [g] 40 Product weight [g] 197 Fastening type Female thread and centring sleeveWith Throughway bore and centring sleeve Pneumatic connection M3 Material information Copper and PTFE-free Cover cap material TPV Housing material aluminiumHard anodised Gripper jaws material High-alloyed steel
