JMDDH-5/2-D-1-M12-C

JMDDH-5/2-D-1-M12-C

$258.92

Solenoid Valve is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:JMDDH-5/2-D-1-M12-C

FESTO Order Number:539079

SKU: JMDDH-5/2-D-1-M12-C Category: Tag:

Description

Valve function 5/2 bi-stable dominated
Actuation type Electrical
Build.width [mm] 42
Normal nominal flow [l/min] 1.200
Operating pressure [bar] 2 to 10
Construction set up Piston pusher
Protection category IP65
Nominal width [mm] 8,0
Pitch dimension [mm] 43
Exhaust function Can be throttled
Sealing principle Soft
installation position arbitrary
Complies to standard ISO 5599-1
Hand assist actuation tentative
ISO-Code 169
Control type pilot operated
Control air supply Internal
Flow direction Not reversible
??berdeckung positive ??berdeckung
Power-on time 100 %
Max. positive test impulse at 0 signal [??s] 3.800
Max. negative test impulse for 1 signal [??s] 4.900
Coil characteristic value 24 V DC: 2,7 W
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Medium temperature [??C] -10 to 50
Sound level [dB(A)] 85
ambient temperature [??C] -10 to 50
Product weight [g] 550
Electrical connection M12x1
Fastening type on connection plateWith throughway bores
Pneumatic connection 1 Connection plate Size 1 to ISO 5599-1
Pneumatic connection 2 Connection plate Size 1 to ISO 5599-1
Pneumatic connection 3 Connection plate Size 1 to ISO 5599-1
Pneumatic connection 4 Connection plate Size 1 to ISO 5599-1
Pneumatic connection 5 Connection plate Size 1 to ISO 5599-1
Seals material HNBRNBR
Housing material Aluminium die casting
Shifting time um [ms] 18
Oscillation strength Transport use test with severity level 1 to FN 942017-4 and EN 60068-2-6
Shock resistance Shock test with degree of severity 2 to FN 942017-5 and EN 60068-2-27
Shifting time um (dominating) [ms] 18
Permitted voltage oscillations ?I 10 %
