Home » Products » MPYE-5-M5-420-B

MPYE-5-M5-420-B

MPYE-5-M5-420-B

$1,037.71

Proportional Directio is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:MPYE-5-M5-420-B

FESTO Order Number:162959

SKU: MPYE-5-M5-420-B Category: Tag:

Description

Nominal width [mm] 2
Actuation type Electrical
Sealing principle Hard
installation position arbitrary
Construction set up Piston pusher
Reset mode Spring magnetic
Safety instructions Safety position MPYE: Move to the blocked centre position if there is a supply line break.
Control type Direct
Flow direction Not reversible
Valve function 5/3 closed
Reverse polarity protection For target value
Operating pressure [bar] 0 to 10
b-value 0.21
C-value [l/sbar] 0,45
Normal nominal flow [l/min] 100
Limit frequency [Hz] 115
Max. hysteresis [%] 0,4
Operating voltage range DC [V] 17 to 30
residual ripple 5 %
TARGET / ACTUAL value Current type 4 – 20 mA
Permission RCM mark
KC-mark KC-EMV
CE certificate (see declaration of conformity) to EU EMC directive
Operating medium Compressed air to ISO 8573-1:2010 [6:4:4]
Information about operating and control medium Oiled operation not possible
Corrosion resistant class KBK 2 – moderate corrosion stress
Medium temperature [??C] 5 to 40
Protection category IP65
ambient temperature [??C] 0 to 50
Product weight [g] 255
Electrical connection M12x14 pinRound shapePlug
Fastening type With throughway bores
Pneumatic connection 1 M5
Pneumatic connection 2 M5
Pneumatic connection 3 M5
Pneumatic connection 4 M5
Pneumatic connection 5 M5
Material information RoHs compliant
Cover material ABSCoated
Seals material NBR
Housing material aluminiumanodized
