MS12-LR-G-PE6

MS12-LR-G-PE6

$1,103.99

Pressure Regulator is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:MS12-LR-G-PE6

FESTO Order Number:564888

SKU: MS12-LR-G-PE6 Category: Tag:

Description

size 12
Model series MS
installation position arbitrary
Construction set up Pre-controlled membrane control valve
Controller function Output pressure constantWith Return current behaviourWith relievingWith Pre-pressure compensation
pressure display with pressure gauge
Operating pressure [bar] 1.15 to 8
Pressure regulation range [bar] 0.15 to 6
Max. pressure hysteresis [bar] 0,04
Flow secondary venting [l/min] <= 600 l/>in
Normal nominal flow [l/min] 12000 to 21000
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]Inert gases
Corrosion resistant class KBK 2 – moderate corrosion stress
Bearing temperature [??C] -10 to 60
Medium temperature [??C] 10 to 50
ambient temperature [??C] 10 to 50
Product weight [g] 4.000
Fastening type pipe installationWith mounting bracketSelectively:
Pneumatic connection 1 Connection plate
Pneumatic connection 2 Connection plate
Cover material PA
Material information RoHs compliant
Cover down material Aluminium wrought alloy
Seals material NBR
Spring material spring steel
Housing material Aluminium die casting
Diaphragm material NBR
Valve tappet material NBRAluminium wrought alloyHigh-alloyed stainless steels
Operating voltage range DC [V] 21.6 to 26.4
Max. electrical power consumption [W] 3,6
Max. power input [A] 0,15
Nominal operating voltage DC [V] 24
residual ripple 10 %
Signal range analogue input 0 – 10 V
KC-mark KC-EMV
CE certificate (see declaration of conformity) to EU EMC directive
Protection category IP65
