MS6-LRE-1/2-D6

$637.17

Electrical Pressure is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:MS6-LRE-1/2-D6

FESTO Order Number:535348

SKU: MS6-LRE-1/2-D6 Category: Tag:

Description

size 6
Model series MS
installation position arbitraryPreferentially vertical
Construction set up Electrically adjustable pressure regulator valve
Short circuit resistance for all electrical connections
Controller function Output pressure constantWith relievingWith Pre-pressure compensation
pressure display with pressure gauge
Operating pressure [bar] 0.8 to 20
Pressure regulation range [bar] 0.3 to 7
Max. pressure hysteresis [bar] 0,25
Normal nominal flow [l/min] 6.500
Control duration at 25 ??C max. 90s
Design inputs No galvanic separationacc. to IEC 61131-2
Nominal operating voltage DC [V] 24
Power input in nominal operating voltage max. 1 A
Power input max. 3.5 A at 24 V DC
Ratio control duration: Pause 1:3
Permitted voltage oscillations ?I 10 %
CE certificate (see declaration of conformity) to EU EMC directive
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]Inert gases
Information about operating and control medium Oiled operation possible (required in further operations)
Corrosion resistant class KBK 2 – moderate corrosion stress
Bearing temperature [??C] -10 to 50
Food compatibility See expanded material information
Medium temperature [??C] 0 to 50
Protection category IP65
ambient temperature [??C] 0 to 50
Product weight [g] 1.280
Cable interface Input: M12x1 plug, 5 pin
Fastening type pipe installationWith AccessoriesSelectively:
Pneumatic connection 1 G1/2
Pneumatic connection 2 G1/2
Seals material NBR
Housing material Aluminium die casting
Diaphragm material NBR
