Home » Products » MS6-SV-1/2-E-10V24-AG

MS6-SV-1/2-E-10V24-AG

MS6-SV-1/2-E-10V24-AG

$1,409.15

Soft-Start/Quick Exha is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:MS6-SV-1/2-E-10V24-AG

FESTO Order Number:548715

SKU: MS6-SV-1/2-E-10V24-AG Category: Tag:

Description

Model series MS
size 6
Pitch dimension [mm] 62
Safety function VentingPrevention of unexpected start up (venting)
Safety Integrity Level (SIL) Venting/ SIL 3Prevention of unexpected start up (venting) / SIL 3
Performance Level (PL) Venting/ up to Category 4, PLePrevention of unexpected start up (venting) / up to Category 4, Performance Level e
Information about force dynamic sampling Switching frequency at least 1/month
Construction set up Piston seat
Freedom from cross-talk no
Actuation type Electrical
Control air supply Internal
Sealing principle Soft
Exhaust function Cannot be throttled
Position detection principle Magnetic piston principle
Complies to standard DIN EN ISO 13849-1
Hand assist actuation none
Reset mode Mechanical spring
Control type pilot operated
Valve function 3/2 closed monostablePressure build-up function
Operating pressure [bar] 3.5 to 10
pressure display with pressure gauge
C-value [l/sbar] 19,3
b-value 0.21
Normal nominal flow [l/min] 4.300
Normal flow Venting 6>0 bar [l/min] 9.000
Max. switching frequency [Hz] 1
Shifting time off [ms] 40
Shifting time on [ms] 130
Power-on time 100 %
Signal condition display LEDPotential free contact
Nominal operating voltage DC [V] 24
Permitted voltage oscillations ?I 10 %
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Corrosion resistant class KBK 2 – moderate corrosion stress
Material information RoHs compliant
Protection category IP65With Socket
Medium temperature [??C] -10 to 50
ambient temperature [??C] -10 to 50
Bearing temperature [??C] -10 to 50
Shock resistance Shock test with degree of severity 2 to FN 942017-5 and EN 60068-2-27
Oscillation strength Transport use test with severity level 2 to FN 942017-4 and EN 60068-2-6
Permission RCM mark
KC-mark KC-EMV
CE certificate (see declaration of conformity) to EU EMC directiveto EU machinery directive
Certified awarding point IFA 1001180
Food compatibility See expanded material information
Fastening type pipe installationWith AccessoriesSelectively:
installation position arbitrary
Product weight [g] 2.000
Pneumatic connection 1 G1/2
Pneumatic connection 2 G1/2
Pneumatic connection 3 G1
Electrical connection Sub-D9 pin
Housing material Aluminium die casting
Seals material NBR
Piston rod material High-alloyed stainless steels
