Description
Cable length [MTR] 2,50
CE certificate (see declaration of conformity) to EU low voltage directive
Material information RoHs compliant
Complies to standard DIN 47100
Line designation Without sign holder
Electrical connection 1, function Field device screen
Electrical connection 1, design Angular
Electrical connection 1, connection type Plug
Electrical connection 1, cable output straight
Electrical connection 1, connection technology Sub-D
Electrical connection 1, number of pins / wires 15
Electrical connection 1, occupied pin / wire 15
Electrical connection 1, fastening type 2x Schraube 4-40 UNC-2A
Electrical connection 2, function Control screen
Electrical connection 2, connection type cable
Electrical connection 2, connection technology Open end
Electrical connection 2, number of pins / wires 15
Electrical connection 2, occupied pin / wire 15
Operating voltage range DC [V] 0 to 30
Nominal operating voltage DC [V] 24
Line properties Cable track capable
Bending radius, permanent cable placement [mm] >= 33 mm
Cable diameter [mm] 6,6
Cable set up 18×0,14
Conductor – nominal cross-section [mm2] 0,140
Wire ends Wire end sleeve
Protection category IP50
Information about protection category In mounted condition
ambient temperature [??C] -30 to +80
Ambient temperature for moving cable placements [??C] -30 to +80
Degree of contamination 3
Cable sleeve material TPE-U(PUR)
Cable shield colour Grey
