Description
Complies to standard EN 61076-2-101
Operating voltage range DC [V] 0 to 60
Operating voltage range AC [V] 0 to 60
Current carrying capacity at 40??C [A] 4,0
Surge voltage strength [kV] 1,5
Cable length [MTR] 7,5
Line properties Cable track capable
Test conditions line Bending radius strength to Festo standardCable track: 5 million cycles, bending radius 75 mmTest conditions on request
Cable diameter [mm] 7,0
Cable set up 5×1
Conductor – nominal cross-section [mm2] 1,00
Protection category IP65IP68IP69K
ambient temperature [??C] -25 to 80
Ambient temperature for moving cable placements [??C] -5 to 80
CE certificate (see declaration of conformity) acc. to EU Low voltage Directiveacc. to EU-RoHS Directive
Material information halogen freeCopper and PTFE-freeRoHs compliantPhosphoric acid ester free
Degree of contamination 3
Corrosion resistant class KBK 2 – moderate corrosion stress
Cable sleeve material TPE-U(PUR)
Cable shield colour Grey
Housing material TPE-U(PUR)
Housing colour black
Seals material NBR
Plug contacts material Copper alloy gold plated
Insulation sleeve material PP
Line designation Without sign holder
Electrical connection 1, function Field device screen
Electrical connection 1, design round
Electrical connection 1, connection type socket / container / ??.
Electrical connection 1, cable output straight
Electrical connection 1, connection technology M12x1 A coded to EN 61076-2-101
Electrical connection 1, number of pins / wires 5
Electrical connection 1, occupied pin / wire 5
Electrical connection 1, fastening type Screw lock
Electrical connection 2, function Control screen
Electrical connection 2, connection type Plug
Electrical connection 2, connection technology M12x1 A coded to EN 61076-2-101
Electrical connection 2, number of pins / wires 5
Electrical connection 2, occupied pin / wire 5
Bending radius, permanent cable placement [mm] 21
Bending radius, moving cable placement [mm] 71
Tolerance cable diameter ?I 0,1 mm
Information about protection category In mounted condition
Special features Oil resistant
Screw lock material brass, nickel-plated
Product weight [g] 227
Electrical connection 2, design round
Electrical connection 2, cable output straight
Electrical connection 2, fastening type Screw lock
