Description
Line designation Without sign holder
Electrical connection 1, function Field device screen
Electrical connection 1, design round
Electrical connection 1, connection type socket / container / ??.
Electrical connection 1, cable output straight
Electrical connection 1, connection technology M12x1 A coded to EN 61076-2-101
Electrical connection 1, number of pins / wires 8
Electrical connection 1, occupied pin / wire 4
Electrical connection 1, fastening type Screw lock
Electrical connection 2, function Control screen
Electrical connection 2, design round
Electrical connection 2, connection type Plug
Electrical connection 2, cable output straight
Electrical connection 2, connection technology M12x1 A coded to EN 61076-2-101
Electrical connection 2, number of pins / wires 4
Electrical connection 2, occupied pin / wire 4
Electrical connection 2, fastening type Screw lock
Operating voltage range DC [V] 0 to 30
Operating voltage range AC [V] 0 to 30
Current carrying capacity at 40??C [A] 2
Surge voltage strength [kV] 0,8
Cable length [MTR] 5,0
Line properties Standard
Cable diameter [mm] 5,6
Tolerance cable diameter ?? 0,2 mm
Cable set up 4×0,34Shielded
Protection category IP67
Information about protection category In mounted condition
ambient temperature [??C] -25 to 85
Ambient temperature for moving cable placements [??C] -5 to 80
CE certificate (see declaration of conformity) to EU EMC directive
Material information halogen freeRoHs compliant
Degree of contamination 3
Corrosion resistant class KBK 2 – moderate corrosion stress
Cable sleeve material TPE-U(PUR)
Cable shield colour Grey
Housing material TPE-U(PUR)
Housing colour black
Insulation sleeve material PP
Complies to standard EN 61076-2-101
Conductor – nominal cross-section [mm2] 0,34
Screw lock material brass, nickel-plated
Seals material NBR
Plug contacts material brass, Gold plated
Bending radius, permanent cable placement [mm] >= 29 mm
Bending radius, moving cable placement [mm] >= 58 mm
