Home » Products » NECU-M-PPG5PP-C1-PN

NECU-M-PPG5PP-C1-PN

NECU-M-PPG5PP-C1-PN

$51.97

Power Supply is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:NECU-M-PPG5PP-C1-PN

FESTO Order Number:5195383

SKU: NECU-M-PPG5PP-C1-PN Category: Tag:

Description

Operating voltage range DC [V] 0 to 24
Current carrying capacity at 40??C [A] 16,0
Surge voltage strength [kV] 4,0
Protection category IP65IP67
ambient temperature [??C] -40 to 85
Material information RoHs compliant
Degree of contamination 3
Corrosion resistant class KBK 1 – low corrosion stress
Housing material Zinc pressure cast, nickel-plated
Plug contacts material Copper allow, nickel and gold plated
Connection frequency 100
Cable output straight
Product weight [g] 109,0
Electrical connection 1, design Angular
Electrical connection 1, connection type socket / container / ??.
Electrical connection 1, connection technology Wiring diagram PP, coding on Pin 2 and 5
Electrical connection 1, number of pins / wires 5
Electrical connection 1, fastening type Push-Pull with lock against accidental pulling
Electrical connection 2, connection technology Spring tension clamp
Cable diameter [mm] 9 to 13
Conductor – nominal cross-section [mm2] 0.75 to 2.5
Information about protection category In mounted condition
Housing colour silver
Report PROFINET
Additional functions meets requirements acc. to AIDA
Electrical connection 1, occupied pin / wire 5
Cable screwing Pg13.5 hexagonal SW22
Conductor nominal cross-section (AWG) AWG18 – 13
Bearing temperature [??C] -40 to 85
Fire inspection UL94 V-0
Seals material NBRTPE-V
