Home » Products » NECU-S-M8G3-HX

NECU-S-M8G3-HX

NECU-S-M8G3-HX

$18.40

Plug is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:NECU-S-M8G3-HX

FESTO Order Number:562024

SKU: NECU-S-M8G3-HX Category: Tag:

Description

Based on standard EN 61076-2-104EN 61984
Operating voltage range DC [V] 0 to 32
Operating voltage range AC [V] 0 to 32
Current carrying capacity at 40??C [A] 4,0
Surge voltage strength [kV] 0,8
Permitted cable diameter [mm] 2.5 to 5.1
Connection cross-section [mm2] 0.14 to 0.34
Protection category IP65IP67
ambient temperature [??C] -25 to 85
Material information Copper and PTFE-freeRoHs compliant
Degree of contamination 3
Corrosion resistant class KBK 1 – low corrosion stress
Housing material PAnickel-platedZinc pressure cast
Plug contacts material Gold plated
Connection frequency 3
Product weight [g] 7,8
Screw lock material brass, nickel-plated
Seals material FKMPUR
Permission c UL us – Recognized (OL)
Electrical connection M8x13 pinPlug straight / Crimp terminal
Permitted individual wire diameter [mm] >= 0.1 mm
Permitted wire diameter [mm] 0.9 to 1.6
Permitted wire insulation PVCTPE-EPP
