Description
size Standard
installation position arbitrary
Packing size 10
Operating pressure complete temperature range [bar] -0.95 to 20
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]Water according to manufacturer declaration at www.festo.com
Information about operating and control medium Oiled operation possible
Corrosion resistant class KBK 3 – severe corrosion stress
Food compatibility See expanded material information
ambient temperature [??C] 0 to 150
Product weight [g] 4,4
Pneumatic connection 1 Male thread G1/8
Material information RoHs compliant
Housing material Nickel-plated brass
Seal type on stud gasket
Max. tightening torque [Nm] 10,0
Thread sealing material FPM
Sleeve material Nickel-plated brass
