NPQH-T-G14-Q6-P10

NPQH-T-G14-Q6-P10

$9.13

Push-In T-Fitting is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:NPQH-T-G14-Q6-P10

FESTO Order Number:578395

SKU: NPQH-T-G14-Q6-P10 Category: Tag:

Description

size Standard
installation position arbitrary
Packing size 10
Operating pressure complete temperature range [bar] -0.95 to 20
Certified awarding point NSF C0523185
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]Water according to manufacturer declaration at www.festo.com
Information about operating and control medium Oiled operation possible
Corrosion resistant class KBK 3 – severe corrosion stress
Food compatibility NSF/ANSI 169siehe Konformit?tserkl?rung
ambient temperature [??C] 0 to 150
Product weight [g] 29,9
Pneumatic connection 1 Male thread G1/4
Material information RoHs compliant
Housing material Nickel-plated brass
Nominal width [mm] 5,00
Seal type on stud gasket
Construction set up Push-pull principle
Max. tightening torque [Nm] 15,0
Pneumatic connection 2 For hose exterior diameter 6 mm
Thread sealing material FPM
Sleeve material Nickel-plated brass
Tube seal, hose seal material FPM
Hose clamping segment material High-alloyed stainless steels
