NVF3-MOH-5/2-K-1/4-EX

NVF3-MOH-5/2-K-1/4-EX

$179.58

Solenoid Valve is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:NVF3-MOH-5/2-K-1/4-EX

FESTO Order Number:535987

SKU: NVF3-MOH-5/2-K-1/4-EX Category: Tag:

Description

Valve function 5/2 or 3/2 mono-stable
Actuation type Electrical
Build.width [mm] 53
Normal nominal flow [l/min] 900
Operating pressure [bar] 2 to 10
Construction set up Plate seat
Reset mode Mechanical spring
CE certificate (see declaration of conformity) to EU EX protection directive (ATEX)
ATEX gas category II 2G
ATEX dust category II 2D
Ex ignition protection type gas Ex h IIC T6 Gb
Ex ignition protection type dust Ex h IIIC T70??C Db
Ex ambient temperature -5??C <= Ta <= +40??C Nominal width [mm] 7 Exhaust function Can be throttled Sealing principle Soft installation position arbitrary Complies to standard VDI/VDE 3845 (NAMUR) Hand assist actuation Ratchetingtentative Control type pilot operated Flow direction Not reversible ??berdeckung negative ??berdeckung b-value 0.33 C-value [l/sbar] 4,2 Shifting time off [ms] 100 Shifting time on [ms] 50 Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] Information about operating and control medium Oiled operation possible (required in further operations) Corrosion resistant class KBK 1 - low corrosion stress Medium temperature [??C] -5 to 40 ambient temperature [??C] -5 to 40 Product weight [g] 280 Fastening type on terminal strip Breathing opening connection Internal Exhaust control connection 84 M5 Pneumatic connection 1 G1/4 Pneumatic connection 2 NAMUR wiring diagram Pneumatic connection 3 G1/4 Pneumatic connection 4 NAMUR wiring diagram Pneumatic connection 5 G1/4 Seals material NBR Housing material Aluminium die casting
