SFAB-1000U-HQ12-2SA-M12-EX2

SFAB-1000U-HQ12-2SA-M12-EX2

$702.59

Flow Sensor is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:SFAB-1000U-HQ12-2SA-M12-EX2

FESTO Order Number:565409

SKU: SFAB-1000U-HQ12-2SA-M12-EX2 Category: Tag:

Description

Permission RCM markc UL us – Recognized (OL)
CE certificate (see declaration of conformity) acc. to EU-EMV Directiveacc. to EU Ex protection Directive (ATEX)acc. to EU-RoHS Directive
KC-mark KC-EMV
Certified awarding point UL E322346
Material information RoHs compliant
Measured parameter flowConsumption
Flow direction P1 -> P2Uni-directional
Measurement principle Thermic
Flow measurement range starting value [l/min] 10,0
Flow measurement range end value [l/min] 1.000
Operating pressure [bar] 0 to 10
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]nitrogen
Medium temperature [??C] 0 to 50
ambient temperature [??C] 0 to 50
Nominal temperature [??C] 23
Accuracy flow value ?? (3% o.m.v. + 0,3% FS)
Repeatability null point in ?? %FS [%FS] 0,2
Repeatability clamp in ?? %FS [%FS] 0,8
Control output 2 x PNP or 2 x NPN switchable
Switch function Window comparatorThreshold comparator
Switching element function NC contactNO contact
Max. output current [mA] <= 100 mA Analogue output 4 - 20 mA Flow characteristic curve starting value [l/min] 0 Flow characteristic curve end value [l/min] 1.000 Output characteristic curve starting value [mA] 4 Output characteristic curve end value [mA] 20 Max. load resistance current output [Ohm] 500 Short circuit resistance yes Operating voltage range DC [V] 15 to 30 Reverse polarity protection for all electrical connections Electrical connection M12x15 pinPlug straight Plug assignment to standard EN 60947-5-2 Fastening type With throughway boresWith Slot railWith Wall / flat holderSelectively: installation position arbitrary Pneumatic connection QS-12 Product weight [g] 600 Housing material PA reinforced Display type Illuminating LCD blue Presentable unit(s) ll/minm3scfscfm Protection category IP65 Pressure drop [mbar] < 100 mbar Corrosion resistant class KBK 2 - moderate corrosion stress ATEX gas category II 3G Ex ignition protection type gas Ex nA IIC T5 X Gc ATEX dust category II 3D Ex ignition protection type dust Ex tc IIIB T80??C X Dc IP54 Ex ambient temperature 0??C <= Ta <= +50??C
