Description
Design For round nut
Complies to standard EN 60947-5-2
Permission RCM markc UL us – Listed (OL)
CE certificate (see declaration of conformity) to EU EMC directive
Special features Oil resistant
Material information halogen freeCopper and PTFE-freeRoHs compliant
Measured parameter Position
Measurement principle Reed magnetic
ambient temperature [??C] -40 to 70
Repeatability [mm] 0,2
Control output Bipolar contact
Switching element function NO contact
Switch on time [ms] <= 1,2 ms
Switch off time [ms] <= 1 ms
Max. switching frequency [Hz] 50
Max. output current [mA] 300
Max. output current in fastening sets [mA] 50
Max. switching capacity AC [VA] 9
Max. switching capacity DC [W] 9
Max. switching capacity DC in fastening sets [W] 1,5
Max. switching capacity AC in fastening sets [VA] 1,5
Voltage drop [V] <= 1,5 V
Short circuit resistance no
Overload resistant Not available
Rated operating voltage DC [V] 24
Operating voltage range AC [V] 5 to 30
Operating voltage range DC [V] 5 to 30
Reverse polarity protection no
Electrical connection 1, connection type cable
Electrical connection 1, connection technology Open end
Electrical connection 1, number of pins / wires 3
Connection outlet direction horizontal
Test conditions line Bending radius strength to Festo standardCable track: 5 million cycles, bending radius 28 mmTest conditions on requestTorsional strength > 300,000 cycles, ??270??/0.1 m
Cable length [MTR] 2,5
Line properties Cable track+robot
Cable sleeve material TPE-U(PUR)
Fastening type Insertable from above into the slotPermanently screwed
Max. tightening torque [Nm] 0,4
installation position arbitrary
Product weight [g] 16,8
Housing material High-alloyed stainless steelsPA reinforced
Switching status indicator LED yellow
Ambient temperature for moving cable placements [??C] -20 to 70
Protection category IP65IP68
