Description
Design For T-slot
Permission RCM mark
CE certificate (see declaration of conformity) to EU EMC directive
Material information Copper and PTFE-freeRoHs compliant
Measurement principle Magnetoresistive
ambient temperature [??C] -20 to 60
Repeatability [mm] 0,2
Control output NPN
Switching element function NO contact
Switch on time [ms] <= 1,3 ms
Switch off time [ms] <= 1,4 ms
Max. output current [mA] 100
Max. switching capacity DC [W] 2,8
Voltage drop [V] <= 1,8 V
Residual current [mA] <= 0,15 mA
Short circuit resistance yes
Overload resistant Available
Operating voltage range DC [V] 10 to 30
Reverse polarity protection for all electrical connections
Electrical connection 1, connection type Plug
Electrical connection 1, connection technology M12x1 A coded to EN 61076-2-101
Electrical connection 1, number of pins / wires 3
Connection outlet direction horizontal
Max. tightening torque plug [Nm] 0,5
Fastening type clamped in t-slotWith AccessoriesInsertable from above into the slot
Torque [Nm] 0,5
Product weight [g] 12
Housing material TPE-U(PU)Aluminium wrought alloyHigh-alloyed stainless steels
Switching status indicator LED yellow
Protection category IP65IP67
