SOPA-CM4H-R1-WQ6-2N-M12

SOPA-CM4H-R1-WQ6-2N-M12

$1,848.75

Air Gap is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:SOPA-CM4H-R1-WQ6-2N-M12

FESTO Order Number:552145

SKU: SOPA-CM4H-R1-WQ6-2N-M12 Category: Tag:

Description

Permission RCM markc UL us – Recognized (OL)
CE certificate (see declaration of conformity) acc. to EU-EMV Directiveacc. to EU-RoHS Directive
KC-mark KC-EMV
Material information Copper and PTFE-freeRoHs compliant
Erfassungsgr??e Abstand
Measurement principle pneumatic
Recording range [??m] 20 to 200
Operating pressure [bar] 4 to 7
Feed pressure [bar] 0.8 to 1.6
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
ambient temperature [??C] 0 to 50
Wiederholgenauigkeit in ?I ??m [??m] 2,5
Control output 2xNPN
Switch function Fenster-KomparatorSchwellwert mit variabler Hysterese
Switching element function Opener/closer switchable
Max. output current [mA] 100
Short circuit resistance yes
Operating voltage range DC [V] 22.8 to 26.4
Reverse polarity protection for all electrical connections
Electrical connection 1, connection type Plug
Electrical connection 1, connection technology M12x1 A coded to EN 61076-2-101
Electrical connection 1, number of pins / wires 5
Electrical connection 1, fastening type Screw lock
Fastening type With throughway boresWith Slot railWith Wall / flat holderSelectively:
Pneumatic connection QS-6
Product weight [g] 690
Housing material PA-verst?rktAluminium eloxiert
Display type Illuminating LCD Multiple
Setting options Teach-inVia display and buttons
Tamper-proof fuse Electronic locking
Protection category IP65
Corrosion resistant class KBK 2 – moderate corrosion stress
