Description
Valve function Exhaust air flow control return function
Pneumatic connection 1 QS-6
Pneumatic connection 2 G1/8
Actuation type Manually
Control air 21 connection QS-6
Setting element hexagon socket
Fastening type Screwable
Normal nominal flow in one-way flow control [l/min] 240
Normal nominal flow in check valve direction [l/min] 120 to 220
Operating pressure [bar] 0.2 to 10
Control pressure [bar] 2 to 10
ambient temperature [??C] -10 to 60
Housing material PBT
installation position arbitrary
Actuation type controlled feedback function pneumatic
Manual venting function tentative
Can be rotated 360 deg/no permanent tilt permitted
Operating pressure complete temperature range [bar] 0.2 to 10
Normal flow In one-way flow control 6 -> 0 bar [l/min] 420
Normal flow In check valve direction 6 -> 0 bar actuated [l/min] 400 to 460
Normal flow In check valve direction 6 -> 0 bar unactuated [l/min] 400 to 460
Normal nominal flow actuated in check valve direction [l/min] 150 to 230
Normal nominal flow not actuated in the check valve direction [l/min] 120 to 220
Shifting time off [ms] 9
Shifting time on [ms] 6
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Medium temperature [??C] -10 to 60
control medium Compressed air to ISO 8573-1:2010 [7:4:4]
Nominal tightening torque [Nm] 3
Tolerance to nominal tightening torque ?I 20 %
Permitted actuation moment regulation disc [Nm] 1
Product weight [g] 28,6
Cover material ES-BE
Material information RoHs compliant
Cover material PBT
Seals material NBR
Banjo bolt material Aluminium wrought alloy
Sleeve material Aluminium wrought alloy
Sleeve material POM
Regulation screw material Brass
