Description
Valve function Unlockable check valve function
Operating pressure [bar] 0.5 to 8
ambient temperature [??C] -5 to 50
installation position arbitrary
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Bearing temperature [??C] -20 to 40
Medium temperature [??C] -5 to 50
Material information RoHs compliant
Fastening type Clip
Product weight [g] 0,17
Control pressure [bar] 0.5 to 8
Corrosion resistant class KBK 4 – particularly severe corrosion stress
Actuation type pneumatic
Normal nominal flow [l/min] 350
Housing material POM
Actuation type controlled feedback function pneumatic
Operating pressure complete temperature range [bar] 0.5 to 8
control medium Compressed air to ISO 8573-1:2010 [7:4:4]
Seals material NBR
