Home » Products » VN-30-H-T6-PQ4-VQ5-RO2-M

VN-30-H-T6-PQ4-VQ5-RO2-M

$289.05

Vacuum Generator is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:VN-30-H-T6-PQ4-VQ5-RO2-M

FESTO Order Number:532662

SKU: VN-30-H-T6-PQ4-VQ5-RO2-M Category: Tag:

Description

Nominal width laval nozzle [mm] 3,00
Pitch dimension [mm] 24
Construction type silencer type open
installation position arbitrary
Ejector characteristic StandardHigh under-pressure
Hand assist actuation tentative
Integrated function Silencer openElectrical switch on valve
Construction set up T-shape
Valve function 2/2
Operating pressure for max. suction volume flow [bar] 3
Operating pressure [bar] 2 to 8
Operating pressure for max. vacuum [bar] 3,7
max. vacuum [%] 93
Nominal operating pressure [bar] 6
Max. suction volume current against atmosphere [l/min] 186,0
Venting time for nominal operating pressure [s] 0,13
Operating voltage range DC [V] 21.6 to 26.4
Electrical power consumption [W] 1,2
Power-on time 100 %
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation not possible
Corrosion resistant class KBK 1 – low corrosion stress
Medium temperature [??C] 0 to 50
Noise level for nominal operating pressure [dB(A)] 78
Protection category IP40
ambient temperature [??C] 0 to 50
Product weight [g] 215
Electrical connection Plug
Fastening type With throughway boresWith Accessories
Pneumatic connection 1 QS-10
Pneumatic connection 3 Silencer open
vacuum connection QS-12
Connection thread material Aluminium wrought alloy anodised
Material information LABS containing materials includedCopper and PTFE-freeRoHs compliant
Seals material NBR
Capture nozzle material POM
Housing material PA reinforcedPOM reinforced
Silencer material POMAluminium wrought alloyPU foam
Screws material Steel
Jet nozzle material Aluminium wrought alloy
Screw connection material brassnickel-plated
