VSVA-B-P53F-ZD-D1-1T1L

$295.65

Solenoid Valve is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:VSVA-B-P53F-ZD-D1-1T1L

FESTO Order Number:8000464

SKU: VSVA-B-P53F-ZD-D1-1T1L Category: Tag:

Description

Valve function 5/3 vented 1 after 2, 4 after 5 closed
Actuation type Electrical
Build.width [mm] 42
Normal nominal flow [l/min] 1.400
Operating pressure [bar] -0.9 to 10
Construction set up Piston pusher
Permission CSA (OL)c UL us – Recognized (OL)
Protection category IP65NEMA 4
Exhaust function drosselbar??ber Drosselplatte??ber Einzelanschlussplatte
Sealing principle Soft
installation position arbitrary
Hand assist actuation RatchetingCoveredtentative
Control type pilot operated
Control air supply external
Flow direction arbitrary
Signal condition display LED
Control pressure [bar] 3 to 10
Flow valve [l/min] 1.700
Flow valve single connection plate [l/min] 1.400
Flow valve pneumatically linked flow optimised [l/min] 1.700
Flow valve pneumatically linked [l/min] 1.400
Shifting time off [ms] 65
Shifting time on [ms] 22
Coil characteristic value 24 V DC: 1,6 W
Surge voltage strength [kV] 2,5
Degree of contamination 3
Permitted voltage oscillations ?I 10 %
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Information about operating and control medium Oiled operation possible (required in further operations)
Corrosion resistant class KBK 0 – No corrosion stressing
Relative humidity 0 – 90 %
ambient temperature [??C] -5 to 50
Product weight [g] 456
Electrical connection Plug-into ISO 5599-2
Fastening type on connection plate
Support air control connection 12/14 Connection plate Size 1 to ISO 5599-2
Exhaust control connection 82/84 Selectively:RecordedNot recorded to standard
Pneumatic connection 1 Connection plate Size 1 to ISO 5599-2
Pneumatic connection 2 Connection plate Size 1 to ISO 5599-2
Pneumatic connection 3 Connection plate Size 1 to ISO 5599-2
Pneumatic connection 4 Connection plate Size 1 to ISO 5599-2
Pneumatic connection 5 Connection plate Size 1 to ISO 5599-2
Material information RoHs compliant
Seals material FKMHNBRNBR
Housing material PAAluminium die casting
Screws material Zinc-plated steel
Nominal tightening current per solenoid 72 mA bis 30 ms
