VZXF-L-M22C-M-B-G1-230-M1-H3A#

$506.31

Angle Seat is a pneumatic component launched by FESTO, which is widely used in the field of industrial automation. Its product quality has been at the leading level in the industry and won the trust and praise of many customers .

Model:VZXF-L-M22C-M-B-G1-230-M1-H3A#

FESTO Order Number:3540768

SKU: VZXF-L-M22C-M-B-G1-230-M1-H3A# Category: Tag:

Description

Construction set up Poppet valve with piston actuator
Actuation type pneumatic
Sealing principle Soft
installation position arbitrary
Fastening type pipe installation
Line connection Threaded muff G1 acc. to DIN ISO 228
Nominal width [mm] 23
Valve function 2/2 closed monostable
Flow direction Not reversible
Medium pressure [bar] 0 to 16
Nominal pressure fitting 16
Exhaust function Cannot be throttled
Reset mode Mechanical spring
Control type Remote controlled
Pneumatic connection female thread G1/8
Operating pressure [bar] 6 to 10
medium Hydraulic oil on the basis of mineral oilInert gasesmineral oilNeutral liquidsWaterFiltered compressed air, filter porosity 200 ??msteam
Flow direction Lower valve seat, for gas and liquid media
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Max. viscosity [mm2/s] 600
Medium temperature [??C] -40 to 200
ambient temperature [??C] -10 to 60
Flow Kv [m3/h] 14,5
Material information LABS containing materials includedRoHs compliant
Instrument housing material red bronze
Material number instrument housing CC499K
Spindle seal material PTFE
Seat seal material PTFE
Product weight [g] 2.000
Corrosion resistant class KBK 0 – No corrosion stressing
Actuator housing material Aluminium
