FESTO ADNGF-20-15-P-A Guided Compact Cylinder — 20mm Bore, 15mm Stroke | Part #554222

FESTO ADNGF-20-15-P-A Guided Compact Cylinder — 20mm Bore, 15mm Stroke | Part #554222

$117.94

The ADNGF series ADNGF-20-15-P-A (Part #554222) is a Guided Compact Cylinder with double-acting configuration, conforming to ISO 21287. Featuring 20mm bore and 15mm stroke. Key highlights: Builds on the compact ADN platform with added precision guidance capability; Built-in magnetic piston supports non-contact position sensing via proximity switches; Plain-bearing guide delivers significantly higher load capacity for pick-and-place tasks. Sealed with TPE-U (PUR), housed in a Wrought aluminum alloy, smooth-anodized body (CRC 2 corrosion resistance).

WhatsApp Inquiry
SKU: ADNGF-20-15-P-A Category: Tag:

Description

Product Overview

The ADNGF-20-15-P-A — part number 554222 — is a premium Guided Compact Cylinder from FESTO’s ADNGF lineup. With double-acting functionality and ISO 21287 compliance, it offers industrial users a dependable solution for their automation needs. FESTO’s rigorous quality control and precision engineering are evident in every aspect of this product’s design and construction.

Key Features

  • Builds on the compact ADN platform with added precision guidance capability
  • Integrated guide rods and yoke plate provide excellent anti-twist protection and side load resistance

Technical Specifications

Parameter Value
Part Number 554222
Model ADNGF-20-15-P-A
Series ADNGF
Product Type Guided Compact Cylinder
Bore Diameter 20 mm
Stroke Length 15 mm
Operating Mode double-acting
Standard ISO 21287
Body Material Wrought aluminum alloy, smooth-anodized
Rod Material High-alloy steel
Seal Material TPE-U (PUR)
Corrosion Resistance CRC 2
Brand FESTO

Applications

This product is suitable for automated pick-and-place, positioning systems, assembly equipment and similar industrial automation environments.

Quality & Compliance

This is a genuine FESTO product, manufactured to FESTO’s global quality standards. All FESTO components undergo rigorous quality testing to ensure reliable performance across diverse industrial operating conditions. This product is manufactured in accordance with ISO 21287 standards.
