FESTO ADNGF-40-5-P-A Guided Compact Cylinder — 5mm Stroke, 40mm Bore | Part #554248

Name: FESTO ADNGF-40-5-P-A Guided Compact Cylinder — 5mm Stroke, 40mm Bore | Part #554248
Brand: FESTO
SKU: ADNGF-40-5-P-A
Price: 180.57 USD
Availability: InStock

$180.57

Engineered for industrial automation, the FESTO ADNGF-40-5-P-A Guided Compact Cylinder (Order #554248) provides double-acting functionality meeting ISO 21287. Featuring 40mm bore and 5mm stroke. Key highlights: Maintains the space-saving ISO 21287 footprint while adding guided functionality; Builds on the compact ADN platform with added precision guidance capability. Constructed with Wrought aluminum alloy, smooth-anodized body and TPE-U (PUR) seals (CRC 2 corrosion resistance).

SKU: ADNGF-40-5-P-A Category: FESTO Tag: FESTO

Description
Reviews (0)

Description

Product Overview

Meeting ISO 21287, the FESTO ADNGF-40-5-P-A Guided Compact Cylinder (Order #554248) represents FESTO’s commitment to industrial automation excellence. Configured for double-acting operation, this ADNGF series component is engineered to perform reliably across a wide range of industrial applications. Its robust design and quality materials ensure consistent operation and extended service intervals.

Key Features

Integrated guide rods and yoke plate provide excellent anti-twist protection and side load resistance
Built-in magnetic piston supports non-contact position sensing via proximity switches

Technical Specifications

Parameter	Value
Part Number	554248
Model	ADNGF-40-5-P-A
Series	ADNGF
Product Type	Guided Compact Cylinder
Bore Diameter	40 mm
Stroke Length	5 mm
Operating Mode	double-acting
Standard	ISO 21287
Body Material	Wrought aluminum alloy, smooth-anodized
Rod Material	High-alloy steel
Seal Material	TPE-U (PUR)
Corrosion Resistance	CRC 2
Brand	FESTO

Applications

Typical deployment scenarios cover automated pick-and-place, positioning systems, assembly equipment and similar industrial automation environments.

Quality & Compliance

This is a genuine FESTO product, manufactured to FESTO’s global quality standards. All FESTO components undergo rigorous quality testing to ensure reliable performance across diverse industrial operating conditions. This product is manufactured in accordance with ISO 21287 standards.
