CPX-AP-I-PN-M12 FESTO PROFINET interface spot

CPX-AP-I-PN-M12 Technical Data

CPX-AP-I-PN-M12 PROFINET interface spot

CPX-AP-I-PN-M12 Festool PROFINET interface is a commonly used model in the field of industrial automation. It is used on valve islands. Because it is a controlled material, it is relatively out of stock in the market.

• Dimensions (W x L x H)45 x 170 x 35 mm
• Diagnostics via LEDDiagnostics per module Network fault Power supply, electronics/sensors Load power supply System diagnostics Service required
• Diagnostics via busAPDD invalid Load switch-off Communication with AP module interrupted Electronics/sensors overvoltage Load overvoltage Electronics/sensors undervoltage Load undervoltage
• Diagnostics per internal communicationModule error Output short circuit/overload Short circuit/overload in sensor supply Undervoltage in load supply
• Configuration supportGSDML file
• Reverse polarity protectionyes
• Max. number of modules80
• Intrinsic current consumption at nominal operating voltage for electronics/sensorsTypically 80 mA
• Intrinsic current consumption at nominal operating voltage loadTypically 5 mA
• Note regarding operating voltageSELV/PELV fixed power supplies required Note voltage drop
• Max. power supply2 x 4 A (external fuse required)
• Nominal DC operating voltage, electronics/sensors24 V
• Nominal operating voltage DC of load24 V
• Power failure bridging10 ms
• Permissible voltage fluctuations for electronics/sensors± 25%
• Permissible voltage fluctuation of load± 25 %
• Power supply, functionIncoming electronics/sensors and load
• Power supply, connection typePlugs
• power supply, connection systemM8x1, A-coded to EN 61076-2-104
• Power supply, number of pins/wires4
• Power transmission, functionOutgoing electronics/sensors and load
• Power transmission, connection typeSocket
• Power transmission, connection technologyM8x1, A-coded to EN 61076-2-104
• Power transmission, number of pins/wires4
• ApprovalRCM trademark
• KC markKC-EMV
• CE mark (see declaration of conformity)To EU EMC Directive
• CE marking (see declaration of conformity)To UK instructions for EMC
• Corrosion resistance class CRC1 – Low corrosion stress
• LABS (PWIS) conformityVDMA24364-B2-L
• Storage temperature-40 °C … 70 °C
• Relative air humidity5 – 95% Non-condensing
• Degree of protectionIP65 IP67
• Note on degree of protectionUnused connections sealed
• Ambient temperature-20 °C … 50 °C
• Product weight186 g
• Max. address volume, outputs1024 Byte
• Max. address volume, inputs1024 Byte
• Field bus interface, electrical isolationyes
• Field bus interface, transmission rate100 Mbit/s
• Fieldbus interfaceEthernet
• Max. cable length50 m system communication
• Note on max. cable lengthPower supply according to nominal voltage
• Fieldbus interface, functionBus connection incoming/outgoing
• Field bus, connection type2x socket
• Field bus, connection systemM12x1, D-coded to EN 61076-2-101
• Field bus, connection pattern4
• Field bus, protocolPROFINET IRT PROFINET RT
• Communication interface, functionSystem communication XF20 OUT / XF21 OUT
• Communication interface, connection type2x socket
• Communication interface, connection technologyM8x1, D-coded according to EN 61076-2-114
• Communication interface, number of pins/wires4
• Communication interface, protocolAP-COM
• Communication interface, shieldingyes
• Type of mountingOn H-rail via accessories With through-hole
• Note on materialsRoHS-compliant
• Material housingPA PC Die-cast zinc, nickel-plated
• Material o-ringFPM
