FLSM-16-L FESTO Ratchet Device: Efficient Rotation, Precise Positioning

In the fields of automation and precision control, ratchet devices play a crucial role in achieving angular positioning and retention. The FLSM-16-L ratchet device from FESTO, with its high performance and accurate positioning characteristics, provides a reliable solution for rotational control.

Product Overview

The FLSM-16-L ratchet device features the following core attributes:

• Specification: Size 16, suitable for medium-load rotational control requirements.
• Rotation Direction: Counterclockwise rotation, meeting the control needs of specific rotation directions.
• Installation Position: Optional, offering flexible installation options to adapt to different application scenarios.
• Paint Wet Insulation Defect Material (PWIS) Compliance: Compliant with the VDMA24364-B1/B2-L standard, ensuring the product’s reliability in humid environments.

Technical Specifications

• Ambient Temperature: -10°C to 60°C, suitable for a variety of environmental conditions.
• Theoretical Torque at 6bar: 2.52 Nm, providing a powerful rotational torque.
• Product Weight: 450g, lightweight design for easy integration and operation.

Material Description

• Housing Material: Refined aluminum alloy, lightweight and sturdy, offering good durability and stability.
• Sleeve Material: Surface-hardened steel, enhancing wear resistance and load-bearing capacity.
• Shaft Material: Surface-hardened steel, ensuring the strength and durability of the shaft.

Application Scenarios

The FLSM-16-L ratchet device is widely used in the following fields:

• Automation Equipment: Achieving precise angular control and positioning in automation equipment.
• Precision Machinery: As a key component in precision machinery, ensuring the accuracy and repeatability of operations.
• Medical Equipment: Providing stable rotational power in medical equipment that requires precise control.
• Testing and Measurement Equipment: Achieving accurate angular adjustment in testing and measurement equipment.

Product Advantages

• Efficient Rotation: Counterclockwise rotation design to meet the rotational needs of specific applications.
• Precise Positioning: Size 16 offers accurate angular control and retention.
• Flexible Installation: Optional installation positions to adapt to a variety of installation environments.
• Durable Materials: Refined aluminum alloy and surface-hardened steel materials ensure the product’s durability and stability.

The FESTO FLSM-16-L ratchet device, with its high performance, accurate positioning, and durable material choices, provides an ideal rotational control component for users. Choosing FESTO means choosing a more reliable and precise rotational control solution.
